Copper Cable Connector Tube Power Line Fittings
- Detail Information
- Product Description
| Application: | Wire Connection | Material: | Copper |
|---|---|---|---|
| Name: | Copper Connecting Tube | Type: | GT Series |
| Place Of Origin: | China | Payment Way: | T/T |
| High Light: |
Connector Tube Power Line Fittings, Copper Cable Connector Tube, ISO9001 Power Line Fittings |
||
GT Series Electrical Accessories Wire Terminal Copper Cable Connector Tube
1.copper connecting tube(oil-plugging)
Description:
Hot Selling GT series are suitable for the connection of the circular wire and hemicycle-sector wire in distribution equipment or power supply cables. They are made of copper tube
Technical parameter:
| D(mm) | d(mm) | L1(mm) | L(mm) | |
| GT-16 | 10 | 6 | 30 | 65 |
| GT-25 | 11 | 7 | 32 | 70 |
| GT-35 | 12 | 8.5 | 34 | 75 |
| GT-50 | 14 | 9.5 | 35 | 80 |
| GT-70 | 16 | 11.5 | 42 | 90 |
| GT-95 | 18 | 13.5 | 43 | 95 |
| GT-120 | 20 | 15 | 47 | 100 |
| GT-150 | 22 | 16.5 | 49 | 105 |
| GT-185 | 25 | 18.5 | 50 | 110 |
| GT-240 | 27 | 21 | 55 | 120 |
| GT-300 | 32 | 23 | 60 | 130 |
| GT-400 | 34 | 26.5 | 65 | 140 |
| GT-500 | 38 | 29 | 70 | 155 |
- copper connecting tubes(passing through)
Description:
GT series hole-passing connection tube is made od T2 copper tube.
Connecting terminal Cable Tube are suitable for the wire in distribution equipment and the electrical equipment.These products are applicable connect the circular wire and hemicycle-sector wire in distribution equipment or power supply cables.
Technical parameter:
| D(mm) | d(mm) | L(mm) | |
| GT-G-16 | 6 | 9 | 56 |
| GT-G-25 | 7 | 10 | 60 |
| GT-G-35 | 8 | 11 | 64 |
| GT-G-50 | 10 | 13 | 72 |
| GT-G-70 | 11 | 15 | 78 |
| GT-G-95 | 13 | 18 | 82 |
| GT-G-120 | 15 | 20 | 90 |
| GT-G-150 | 17 | 22 | 94 |
| GT-G-185 | 19 | 25 | 100 |
| GT-G-240 | 21 | 27 | 110 |
| GT-G-300 | 23 | 30 | 120 |
| GT-G-400 | 27 | 34 | 130 |
